JNJ-1000-12/JNJ-1500-12 Off Grid Solar Inverter
Hover to zoom
products.categories.3
JNJ-1000-12/JNJ-1500-12 Off Grid Solar Inverter
High-Efficiency Off Grid Solar Inverter for Residential and Commercial Applications
Features
- Pure sine wave solar inverter
- Built-in 40A MPPT solar charger
- PV input voltage range 20~150VDC (for 1000W), 30~150VDC (for 1500W)
- Built-in anti-dust kit for harsh environment
- Smart battery charge design to optimize battery life
- Meet rich customized demands
- Solar energy is provided directly to the load first
Specifications
Model NumberJNJ-1000-12/JNJ-1500-12
Rated Power1000VA/1500VA
AC Input Voltage220VAC
AC Input Selectable Voltage Range170V~280VAC(For Personal Computer), 90V~280VAC(For Home Appliances)
AC Input Frequency Range50HZ
AC Output Voltage Regulation220VAC±5%
AC Output Surge Power2000VA/3000VA
AC Output Efficiency(Peak) PV to INV98%
AC Output Efficiency(Peak) Battery to INV94%
AC Output Transfer Time10ms
Battery Voltage12VDC
Battery Floating Charge Voltage13.5VDC
Battery Overcharge Protection16VDC
Solar Charger TypeMPPT
Maximum PV Array Power1000W/1500W
MPPT Range @ Operating Voltage20~150VDC/30~150VDC
Maximum PV Array Open Circuit150VDC
Maximum Solar Charging Current40A
Maximum AC Charging Current40A
Maximum Solar+AC Charging Current80A
Humidity5%~95%RH
Operating Temperature-10~+50°C
Compliance SafetyCE
